Differential Ring and Pinion (10, 10)
Motive Gear stock performance ring and pinions are excellent replacements for OE. Experienced installers prefer our ring and pinions for easy setup, superior strength, quality, and our vast ratio selection. Motive Gear produces the industry's widest range of OEM replacement ring and pinions. Engineered to the highest standards, every Motive Gear product goes through rigid quality control processes in our in-house lab. In combination with Motive Gear's performance and axle divisions: Motive Gear Performance and TEN Factory, there simply isn't a better value in drivetrain components.
D35-513F Application Notes
- For Dana 35 IFS
- 5.13 Ratio
Warranty
1 Year or 50,000 Miles
D35-513F Specifications
App Model
Dana 35 Standard
Cover Bolt Quantity
10, 10
Differential Case Design Type
Dana 35, Dana 35
Gear Ratio
5.13, 5.13
Pinion Gear Tooth Quantity
8, 8
Pinion Shaft Diameter
1.406 (Inch), 1.406 (Inch)
Pinion Spline Count
26, 26
Position
Front
Prop 65 Long Label
WARNING: Reproductive Harm - www.p65warnings.ca.gov
Prop 65 Short Label
WARNING: Cancer - www.p65warnings.ca.gov
Prop 65 Y N
N
Ratio
5.13
Ring Gear Bolt Quantity
8, 8
Ring Gear Material
8620 Steel, 8620 Steel
Ring Gear Outside Diameter
7.562 (Inch), 7.562 (Inch)
Ring Gear Rotation
Reverse, Reverse
Ring Gear Tooth Quantity
41, 41
Taxonomy A
LD Differential, LD Differential, LD Differential, LD Differential
Taxonomy B
Ring and Pinion, Ring and Pinion, Ring and Pinion
Taxonomy C
Front, Front, Front
Taxonomy D
5.13, 5.13, 5.13
Vehicle Applications
- 1990 Ford Bronco II
- 1991 – 1994 Ford Explorer
- 1990 – 1997 Ford Ranger
- 1994 – 1997 Mazda B4000
- 1991 – 1994 Mazda Navajo
